Laboratory Travelling Microscope

Laboratory Travelling Microscope Price And Quantity

• Minimum Order Quantity 1 Unit

• Vernier Scale Length 220 mm X direction, 150 mm Y direction.
• Slide Movement Horizontal (X-axis) and vertical (Y-axis) movements with smooth guideways.
• Gross Weight Approx. 8-10 kg including packaging.
• Packing Supplied in sturdy wooden or thermocol box for safe transport.
• Paint Finish Chemically treated and powder coated paint for long-lasting durability.
• Scale Reading Accuracy 0.01 mm by vernier scale.
• Optical Quality Precision ground, full achromatic objectives for clear, sharp images.
• Leveling Arrangement Three leveling screws for precise horizontal alignment.
• Suitable Applications Physics, metrology, material science, research laboratory measurements.
• Clamp Mechanism Stage spring clips for holding specimens firmly.
• Base Material Heavy-duty cast iron for vibration-free operation.

Laboratory Travelling Microscope Product Specifications

• Objective Achromatic Achromatic objectives 15x/20x, anti-reflective coated optics.
• Working Stage Metallic stage with glass plate, with X-Y horizontal movement 150 mm x 200 mm (approximate).
• Coarse Adjustment Range Provided by rack and pinion mechanism for substantial movement of the microscope tube.
• Condenser Not applicable (used for transmitted illumination, not typical in this design).
• Interface Manual, optical observation.
• Drawtube Adjustable metallic drawtube for smooth focus movement.
• Focus System Rack and pinion coarse focus with screw micrometer fine adjustment.
• View Head Monocular head, 360° rotatable.
• Focal Distance Can be adjusted with rack and pinion focusing mechanism.
• Image Format Visual observation, not digital.
• Spare Parts Vernier scale, glass stage plate, mirror, objectives, eyepiece.
• Resolution Typically up to 0.01 mm using the vernier scale.
• Theory A Laboratory Travelling Microscope is a precision instrument used for measuring small lengths, thicknesses, and diameters with high accuracy, employing a finely graduated scale and vernier arrangement for linear measurements and fine adjustment.
• Eyepiece Tube Straight monocular tube with fine-tuned focusing.
• Interpupillary Distance Not adjustable (single eyepiece monocular design).
• Magnification Up to 15x (combination of 10x eyepiece and 15x objective).
• Frame Rate Not applicable (no digital/video system).
• Fine Adjustment Range Micrometer screw adjustment for precise measurement.
• Still Image Capture Resolution Not applicable (optical observation only).
• Focus Range Vertical movement typically 150 mm.
• Features Heavy cast iron base, three leveling screws, precise measuring scale, smooth sliding carriage, fine adjustment, anti-reflective optics, robust and stable construction.
• Video Capture Resolution Not applicable (optical observation only).
• Illumination External light source or mirror illumination, natural light compatible.
• Dimensions Approx. 370 mm (L) x 210 mm (W) x 430 mm (H).
• Light Source Mirror for ambient light; external LED lamp mountable.
• Sensor Not Applicable (optical system only).
• Eyepieces 10x (standard), optional 15x.

• Vernier Scale Length 220 mm X direction, 150 mm Y direction.
• Slide Movement Horizontal (X-axis) and vertical (Y-axis) movements with smooth guideways.
• Gross Weight Approx. 8-10 kg including packaging.
• Packing Supplied in sturdy wooden or thermocol box for safe transport.
• Paint Finish Chemically treated and powder coated paint for long-lasting durability.
• Scale Reading Accuracy 0.01 mm by vernier scale.
• Optical Quality Precision ground, full achromatic objectives for clear, sharp images.
• Leveling Arrangement Three leveling screws for precise horizontal alignment.
• Suitable Applications Physics, metrology, material science, research laboratory measurements.
• Clamp Mechanism Stage spring clips for holding specimens firmly.
• Base Material Heavy-duty cast iron for vibration-free operation.

Laboratory Travelling Microscope Trade Information

• Supply Ability 10 Unit Per Week
• Delivery Time 1 Week
